Add to Cart for Discount| Speed (rpm): | 88 |
| Rated Torque (lb-in): | 274 |
| Motor HP: | 1/2 |
| Volts: | 230/460 |
| Hz: | 60 |
| Phases: | 3 |
| Amps: | 1.60/0.78 |
| Gear Ratio: | 20 |
| `Torque at 10Hz: | 210 |
| Length H (inch): | 14.06 |
| Weight (lbs): | 70 |
| Connection Diagram: | 07410979 |
| Product Type: | 56R1BSPP-50JW/H |
| HP Decimal: | 0.5 |
STANDARD FEATURES
- Totally Enclosed IP-69K rating. Meets EU Hygienic standard for food machinery.
- Stainless Steel construction throughout. Sealed against water and dust ingress.
- 230/460VAC, 1/2 HP inverter-duty, 3-phase winding
- Large water tight terminal box in 12 o’clock position for easy access.
- Gearmotors mount via face or base of gearhead. Optional mounting accessories available.
- See our dimension drawing, INFM0441, page 2, for details on mounting orientation/install instructions.
- Food grade lubricant
- The gearmotors are compatible with a wide selection of AC speed controls (VFDs). Make sure to use an appropriate control enclosure for your application.
- The terminal box can be rotated by rotating the motor in 90-degree increments
